180℃ High temperature wear resistance Single-core Silicone Wire & Cable
Single-core Silicone High Temperature Wire & Cables have excellent high temperature and low temperature resistance, excellent electrical insulation performance, excellent chemical stability, high voltage resistance, aging resistance, long service life, and flexibility for easy installation.
GET A QUOTE
Characteristic：
- Rated voltage: 300/500V
- Operating temperature: -60~+180℃
- Conductor: Bare copper wire or tinned copper stranded wire
- Insulation: Silicone rubber
- Color:Customizable
Industry Standard：
- Q31/0114000209C026-2017
Selection parameter
|
Standard section（mm²） |
Conductor structure |
Insulation thickness（mm） |
Average Outer Diameter（mm） |
Maximum conductor resistance at 20°C（Ω/km) |
|
0.10 |
12×0.10 |
0.45 |
1.30 |
188 |
|
0.20 |
12×0.15 |
0.65 |
1.80 |
95 |
|
0.30 |
16×0.15 |
0.60 |
1.85 |
71.2 |
|
0.40 |
23×0.15 |
0.50 |
1.90 |
49.6 |
|
0.50 |
28×0.15 |
0.60 |
2.20 |
40.1 |
|
0.75 |
42×0.15 |
0.70 |
2.60 |
26.7 |
|
1.0 |
32×0.20 |
0.75 |
2.80 |
20.0 |
|
1.5 |
48×0.20 |
0.75 |
3.10 |
13.7 |
|
2.0 |
40×0.25 |
0.85 |
3.40 |
9.90 |
|
2.5 |
49×0.25 |
0.85 |
3.70 |
8.21 |
|
4.0 |
56×0.30 |
0.70 |
4.30 |
5.09 |
|
6.0 |
84×0.30 |
0.80 |
5.20 |
3.39 |
|
10 |
84×0.40 |
1.00 |
6.60 |
1.95 |
|
16 |
126×0.40 |
1.20 |
8.40 |
1.24 |
|
25 |
196×0.40 |
1.40 |
10.40 |
0.795 |
