Silicone High Voltage High Temperature Wire & Cable
Silicone High Voltage High Temperature Wire & Cable is excellent high temperature and low temperature resistance, excellent electrical insulation performance, excellent chemical stability, high voltage resistance, aging resistance, and long service life. It is also flexible and easy to install.
GET A QUOTE
Application：
“The product is suitable for F-class, H-class insulated motors and electrical lead wires with rated AC voltages of 690V, 1140V, and below. It is widely used in marine, defense, train, and other high-power motors.”
Characteristic：
- Rated voltage: 500V (690V), 1000V (1140V).
- Operating temperature: -60~+180°C.
- Conductor: Bare copper wire or tinned copper stranded wire.
- Insulation: Silicone rubber.
- Color: Customizable.
Industry Standard
- JB/T 6213.4-2006
Selection parameter
|
Conductor structure |
Insulation thickness（mm） |
Wire outer diameter（mm） |
Conductor DC resistance at 20°C （Ω/km） |
||||
|
Nominal cross section （mm2） |
Number of wires/wire diameter （mm） |
Conductor outer diameter （mm） |
500V |
1000V |
500V |
1000V |
|
|
0.5 |
28/0.15 |
0.90 |
1.0 |
1.2 |
2.90 |
3.30 |
40.1 |
|
0.75 |
24/0.20 |
1.15 |
1.0 |
1.2 |
3.20 |
3.60 |
26.7 |
|
1 |
32/0.20 |
1.30 |
1.0 |
1.2 |
3.30 |
3.70 |
20 |
|
1.5 |
48/0.20 |
1.60 |
1.0 |
1.2 |
3.60 |
4.0 |
13.7 |
|
2 |
40/0.25 |
1.85 |
1.0 |
1.2 |
3.90 |
4.30 |
9.9 |
|
2.5 |
49/0.25 |
2.00 |
1.0 |
1.2 |
4.00 |
4.40 |
8.21 |
|
4 |
56/0.30 |
2.80 |
1.2 |
1.4 |
5.20 |
5.60 |
5.09 |
|
6 |
84/0.30 |
3.60 |
1.2 |
1.5 |
6.00 |
6.60 |
3.39 |
|
10 |
84/0.40 |
4.60 |
1.4 |
1.6 |
7.40 |
7.80 |
1.95 |
|
16 |
126/0.40 |
5.80 |
1.4 |
1.6 |
8.60 |
9.0 |
1.24 |
|
25 |
196/0.40 |
7.60 |
1.6 |
1.8 |
10.80 |
11.2 |
0.795 |
|
35 |
494/0.30 |
8.80 |
1.8 |
2.0 |
12.40 |
12.80 |
0.565 |
|
50 |
396/0.40 |
10.60 |
2.0 |
2.2 |
14.60 |
15.0 |
0.393 |
|
70 |
551/0.40 |
12.80 |
2.0 |
2.2 |
16.80 |
17.20 |
0.277 |
|
95 |
760/0.40 |
14.80 |
2.2 |
2.5 |
19.20 |
19.80 |
0.210 |
|
120 |
608/0.50 |
16.5 |
2.2 |
2.5 |
21.00 |
21.50 |
0.164 |
|
150 |
760/0.50 |
18.2 |
2.4 |
2.6 |
23.00 |
23.40 |
0.132 |
|
185 |
925/0.50 |
20.0 |
2.4 |
2.6 |
24.80 |
25.20 |
0.108 |
|
240 |
1221/0.50 |
23.0 |
2.6 |
2.8 |
28.20 |
28.60 |
0.0817 |
