PTFE cable Salt and alkali resistant corrosion resistant Silicone Sheathed Shielded Wire & Cable

PTFE Core Silicone Sheathed Shielded High Temperature Wire & Cable is excellent high temperature and low temperature resistance, excellent electrical insulation performance, excellent chemical stability, high voltage resistance, aging resistance, and long service life. It is also flexible and easy to install.

GET A QUOTE

Application：

“Suitable for use in various mobile machines, steel, aviation, power plants, petrochemicals, and other high-temperature environments with rated AC voltages of 450/750V and below.”

Characteristic：

Rated voltage: 300/500V
Operating temperature: -60~+200°C
Conductor: Tinned copper stranded wire
Insulation: FEP (Fluorinated Ethylene Propylene)
Jacket: Silicone rubber
Color: Customizable

Industry Standard

Q/IRMV3 -2008

Selection parameter

Number of cores×section （mm2）	oCnductor structure Number of wires/wire diameter（mm）	Insulation thickness （mm）	Insulation outer diameter （mm）	Sheath thickness （mm）	Average outer diameter （mm）	Conductor DC resistance at 20°C （Ω/km）
1×0.4	48/0.10	0.50	1.80	0.80	4.0	53.1
1×0.75	19/0.23	0.60	2.35	0.65	4.10	24.6
1×1.5	19/0.32	0.60	2.80	1.20	5.80	12.7
3×0.08	7/0.12	0.20	0.76	0.70	3.40	245
4×0.08	7/0.12	0.20	0.76	0.80	4.0	245
5×0.08	7/0.12	0.20	0.76	0.80	4.20	245
6×0.08	7/0.12	0.20	0.76	1.10	5.20	245
2×0.12	7/0.15	0.25	0.95	0.70	3.90	163
3×0.12	7/0.15	0.25	0.95	0.70	4.0	163
4×0.15	7/0.15	0.25	0.95	1.0	4.80	163
5×0.12	7/0.15	0.25	0.95	0.90	4.90	163
6×0.12	7/0.15	0.25	0.95	1.0	5.40	163
7×0.12	7/0.15	0.25	0.95	1.0	5.50	163
2×0.2	7/0.20	0.25	1.10	0.80	4.30	90.4
3×0.2	7/0.20	0.25	1.10	0.80	4.50	90.4
4×0.2	7/0.20	0.25	1.10	1.0	5.20	90.4
5×0.2	7/0.20	0.25	1.10	1.0	5.50	90.4
6×0.2	7/0.20	0.25	1.10	1.2	6.20	90.4
7×0.2	7/0.20	0.25	1.10	1.2	6.20	90.4
8×0.2	7/0.20	0.25	1.10	1.2	6.50	90.4
10×0.2	7/0.20	0.25	1.10	1.40	7.60	90.4
16×0.2	7/0.20	0.25	1.10	1.50	8.60	90.4
19×0.2	7/0.20	0.25	1.10	1.50	9.0	90.4
2×0.35	19/0.16	0.25	1.30	1.0	5.0	53.1
3*0.35	19/0.16	0.25	1.30	1.0	5.40	53.1
4×0.35	19/0.16	0.25	1.30	1.20	6.20	53.1
5×0.35	19/0.16	0.25	1.30	1.20	6.50	53.1
6×0.35	19/0.16	0.25	1.30	1.20	7.0	53.1
7×0.35	19/0.16	0.25	1.30	1.20	7.0	53.1
8×0.35	19/0.16	0.25	1.30	1.40	7.80	53.1
2×0.5	19/0.18	0.25	1.40	1.0	5.20	40.1
3×0.5	19/0.18	0.25	1.40	1.0	5.50	40.1
4×0.5	19/0.18	0.25	1.40	1.10	6.10	40.1
5×0.5	19/0.18	0.25	1.40	1.20	6.80	40.1
6×0.5	19/0.18	0.25	1.40	1.30	7.20	40.1
7×0.5	19/0.18	0.25	1.40	1.30	7.40	40.1
2×0.75	19/0.23	0.25	1.70	1.20	6.30	24.6
3×0.75	19/0.23	0.25	1.70	1.40	7.0	24.6
4×0.75	19/0.23	0.25	1.70	1.60	8.0	24.6
5×0.75	19/0.23	0.25	1.70	1.50	8.20	24.6
6×0.75	19/0.23	0.25	1.70	1.50	8.60	24.6
7×0.75	19/0.23	0.25	1.70	1.60	8.80	24.6
2×1	19/0.26	0.25	1.80	1.20	6.60	20.4
3×1	19/0.26	0.25	1.80	1.40	7.30	20.4
4×1	19/0.26	0.25	1.80	1.40	7.80	20.4
7×1	19/0.26	0.25	1.80	1.60	8.60	20.4
2×1.5	19/0.32	0.30	2.25	1.30	7.70	12.7
3×1.5	19/0.32	0.30	2.25	1.40	8.20	12.7
4×1.5	19/0.32	0.30	2.25	1.40	8.50	12.7
7×1.5	19/0.32	0.30	2.25	1.60	10.50	12.7
2×2.5	19/0.41	0.40	2.80	1.50	9.20	7.43
3×2.5	19/0.41	0.40	2.80	1.50	9.60	7.43
4×2.5	19/0.41	0.40	2.80	1.60	10.60	7.43
7×2.5	19/0.41	0.40	2.80	1.80	12.6	7.43
