0.75mm Marine High Temperature Heat Resistant Salt & Alkali-Resistant Oil Resistant PE insulated cable
The products are specially used for power, lighting and general control and instrument circuits of various ships in rivers and seas and offshore oil platforms and other water structures.
GET A QUOTE
Product model: 0.75mm
Product name: Marine High Temperature Heat Resistant Salt & Alkali-Resistant Oil Resistant PE insulated cable
Withstand voltage level: 150/250V (300V)
Temperature grade: -40℃-+125℃
Applications:
Marine High Temperature Heat Resistant Salt & Alkali-Resistant Oil Resistant PE insulated cables are specially used for power, lighting and general control and instrument circuits of various ships in rivers and seas and offshore oil platforms and other water structures.
Product Features:
Marine High Temperature Heat Resistant Salt & Alkali-Resistant Oil Resistant PE insulated cable has been certified by CCS China Classification Society; it has the characteristics of low smoke, halogen-free, low toxicity, and is resistant to mold and salt spray corrosion.
Industry Standard:
IEC60228, IEC60092-350, IEC60092-360, IEC60092-376, IEC60332-1, IEC60332-3, IEC60331, IEC61034, IEC60754, GJB150, GJB1916
Technical Parameters
| Specification | conductor structure | Nominal degree of insulation mm |
Sheath nominal thickness mm |
Armored wire diameter am |
Cable outer diameter mm |
Calculated weight of cable kg/km |
||
|---|---|---|---|---|---|---|---|---|
| Number of cores × nominal cutting area mm2 |
Number of strands/single wire nominal diameter, mm |
Inner sleeve | coat | nominal value |
maximum value |
CKOJ 185/DC | ||
| 2×0.75 | 7/0.37 | 0.7 | — | 1.1 | 0.2 | 9.3 | 11 | 102 |
| 4×0.75 | 7/0.37 | 0.7 | — | 1.1 | 0.2 | 10.5 | 12 | 137 |
| 7×0.75 | 7/0.37 | 0.7 | — | 1.2 | 0.2 | 12.2 | 14 | 192 |
| 10×0.75 | 7/0.37 | 0.7 | — | 1.3 | 0.3 | 15.6 | 18 | 299 |
| 14×0.75 | 7/0.37 | 0.7 | — | 1.3 | 0.3 | 16.7 | 19 | 360 |
| 19×0.75 | 7/0.37 | 0.7 | — | 1.4 | 0.3 | 18.5 | 21 | 445 |
| 24×0.75 | 7/0.37 | 0.7 | — | 1.5 | 0.3 | 21.3 | 24.5 | 550 |
| 30×0.75 | 7/0.37 | 0.7 | — | 1.5 | 0.3 | 22.4 | 25.3 | 633 |
| 37×0.75 | 7/0.37 | 0.7 | — | 1.6 | 0.3 | 24.2 | 27.5 | 743 |
Note: Products with other specifications can also be customized according to customer needs
