High cold low temperature multi core railway/wind power wire & cable
High cold low temperature multi core railway/wind power wire & cable possess the ability to adapt to the extreme cold environments of corresponding levels. These products demonstrate excellent cold resistance and are widely used as dedicated connection cables for power supply and control circuits in cold regions and environments, particularly in railway vehicles. Even under ultra-low temperature conditions, the cables maintain outstanding physical, mechanical, electrical, and aging resistance properties without cracking. This greatly enhances the safety and lifespan of the cables.
GET A QUOTE
Application：
TST-GH-M High cold low temperature multi core railway/wind power wire & cable can be widely used under cold conditions as a special connecting cable for rail vehicle power supply and control lines in corresponding cold areas and environments.
Characteristic：
- Temperature resistance: -60 to 180°C
- Insulation strength: >100Mpa
- Sheath strength: >8Mpa
- Insulation layer/wear resistance, non-deformable
- Non-deformable
- Wear resistance
- Oxidation resistance
- Ultra-low temperature resistance
- Anti-freeze and cold-resistant
- Excellent mechanical properties
- Superior electrical insulation performance
- Good chemical stability
Industry Standard:
- EN45545-2
Structure：
- Conductor: Tin-plated copper conductor, either 5-class or 6-class structure.
- Insulation: Low smoke halogen-free polymer TST-101.
- Shielding: Tin-plated copper or silver-plated copper braid.
- Jacket/Sheath: Silicone rubber material.
- Fire resistance: Complies with EN45545-2 R15/R16 HL3.
Selection parameter
| Number of cores * nominal cross section/mm | Insulation thickness/ mm | Insulation outer diameter/ mm |
Cable outer diameter/ mm |
Weight Kg/km | ||
|---|---|---|---|---|---|---|
| 1.30±0.1 | 1.2 | 5.5±0.2 | 43.1 | 338 | ||
| 5×0.50 | 0.2 | 1.30±0.1 | 1.2 | 5.7±0.2 | 50.2 | 392 |
| 4×0.5 | 0.2 | 1.30±0.1 | 1.2 | 6.0±0.2 | 58.5 | 451 |
| 5×0.50 | 0.2 | 1.30±0.1 | 1.2 | 6.4±0.2 | 67.2 | 511 |
| 6×0.5 | 0.2 | 1.30±0.1 | 1.2 | 6.8±0.2 | 76 | 573 |
| 7×0.50 | 0.2 | 1.30±0.1 | 1.2 | 6.8±0.2 | 81.2 | 634 |
| 8×0.50 | 0.2 | 1.30±0.1 | 1.2 | 7.2±0.2 | 90 | 692 |
| 2×0.75 | 0.2 | 1.55±0.1 | 1.2 | 6.0±0.2 | 53.6 | 372 |
| 3×0.75 | 0.2 | 1.55±0.1 | 1.2 | 6.2±0.2 | 64 | 442 |
| 4×0.75 | 0.2 | 1.55±0.1 | 1.2 | 6.6±0.2 | 75.8 | 516 |
| 5×0.75 | 0.2 | 1.55±0.1 | 1.2 | 7.1±0.2 | 88.1 | 602 |
| 6×0.75 | 0.2 | 1.55±0.1 | 1.2 | 7.6±0.2 | 100.5 | 697 |
| 7×0.75 | 0.2 | 1.55±0.1 | 1.2 | 7.6±0.2 | 108.8 | 1043 |
| 8×0.75 | 0.2 | 1.55±0.1 | 1.2 | 8.0±0.2 | 121.2 | 1262 |
| 2×1.0 | 0.2 | 1.65±0.1 | 1.2 | 6.2±0.2 | 58.5 | 396 |
| 3×1.0 | 0.2 | 1.65±0.1 | 1.2 | 6.5±0.2 | 70.5 | 482 |
| 4×1.0 | 0.2 | 1.65±0.1 | 1.2 | 6.9±0.2 | 84.1 | 549 |
| 5×1.0 | 0.2 | 1.65±0.1 | 1.2 | 7.4±0.2 | 98.1 | 623 |
| 6×1.0 | 0.2 | 1.65±0.1 | 1.2 | 7.9±0.2 | 112.2 | 724 |
| 7×1.0 | 0.2 | 1.65±0.1 | 1.2 | 7.9±0.2 | 122.1 | 1086 |
| 8×1.0 | 0.2 | 1.65±0.1 | 1.2 | 7.9±0.2 | 136.2 | 1321 |
