Customized cable GNFR500-02 500V Fire Resistance Wire High-temperature heat-resistant cables 350℃ 1200℃
High-temperature heat-resistant cables has electrical insulation properties, is resistant to corona and partial discharge, and has no change in electrical insulation properties at high temperatures; it has heat resistance properties, has good mechanical properties at 200℃~350℃, and is resistant to hot gas aging; it is resistant to radiation and can Under the irradiation of strong rays, the tensile strength and elongation do not change significantly; it is resistant to organic solvents, ozone, enzymes, and corrosion resistance; it does not absorb water, is non-flammable, and is sensitive to flames.
GET A QUOTE
Product number
- GNFR500-02
Industry standard
- Q31/0114000209C025-2017
Product Features
- Rated voltage: 500V
- Working temperature: -60℃~300℃ (up to 350℃ in short time)
- Conductor: nickel-plated stranded wire
- Insulation: double layer insulation
- Color: light yellow
Features/Use
It has electrical insulation properties, is resistant to corona and partial discharge, and has no change in electrical insulation properties at high temperatures; it has heat resistance properties, has good mechanical properties at 200℃~350℃, and is resistant to hot gas aging; it is resistant to radiation and can Under the irradiation of strong rays, the tensile strength and elongation do not change significantly; it is resistant to organic solvents, ozone, enzymes, and corrosion resistance; it does not absorb water, is non-flammable, and is sensitive to flames.
Delivery requirements:
According to the contractual agreement between the two parties, short-section delivery of not less than 10 meters is allowed. Its quantity should not exceed 10% of the total length of delivery
Technical Parameters
| Nominal cross section(mm2) |
Conductor structure Root number / diameter(mm) |
Insulation thickness (mm) |
Outside diameter control (mm) |
conductor DC resistance (Q/km) |
Packing length (m) |
|---|---|---|---|---|---|
| 200 | 200 | ||||
| 200 | 200 | ||||
| 1 | 32/0.20 | 0.4 | 2.2士0.2 | 200 | 200 |
| 1.25 | 40/0.20 | 0.4 | 2.4士0.2 | 200 | 200 |
| 1.5 | 48/0.20 | 0.4 | 2.6土0.2 | 200 | 100 |
| 2.5 | 35/0.30 | 0.4 | 3.0土0.3 | 100 | 100 |
| 4 | 56/0.30 | 0.4 | 3.7±0.3 | 100 | 100 |
| 6 | 84/0.30 | 0.4 | 4.6士0.3 | 100 | 100 |
| 10 | 140/0.30 | 0.4 | 5.6士0.3 | 100 | 100 |
Note: Products of other specifications can be produced according to the agreement between the supplier and the buyer.
