1000℃ High-temperature heat-resistant cable & wire GN1000 300V cable
1000℃ High-temperature heat-resistant cable is a wire and cable used in various electrical devices that require fire protection in special environments such as metallurgy, thermal engineering, petroleum, chemical industry, natural gas, and kerosene.Electrical Cable For High Temperature GN1000 Temperature resistant 1000℃
GET A QUOTE
Product number:
- GN1000
Industry Standard:
- Q31/0114000209C025-2017
Product Features
- Rated voltage: 300/500V
- Temperature range: 800℃, can withstand temperatures up to 1000℃ in a short period of time
- Conductor: Pure nickel stranded wire
- Color: earthy yellow, you can choose black gauze, red gauze, etc.
Features/Use
Product application: 1000℃ High-temperature heat-resistant cable is a wire and cable used in various electrical devices that require fire protection in special environments such as metallurgy, thermal engineering, petroleum, chemical industry, natural gas, and kerosene.
Delivery requirements
Delivery length: short line segments of not less than 10 meters are allowed, but their quantity cannot exceed 10% of the total delivery quantity; laying conditions: fixed laying, plus flame combustion, no harmful and toxic gases
Product parameters:
| Nominal cross section (mm2) | Conductor structure number of wires/wire diameter (mm) |
Insulation thickness (mm) | Packing length (m) |
|---|---|---|---|
| 0.5 | 7 × 0.30 | 3.6土0.5 | 200 |
| 0.75 | 11 × 0.30 | 3.8±0.5 | 200 |
| 1 | 14 × 0.30 | 4.1±0.5 | 200 |
| 1.5 | 21 × 0.30 | 4.5±0.5 | 100 |
| 2 | 28 × 0.30 | 4.8±0.5 | 100 |
| 2.5 | 35 × 0.30 | 5.1土0.5 | 100 |
| 4 | 56 × 0.30 | 5.6士0.5 | 100 |
| 6 | 84 × 0.30 | 6.5±0.5 | 100 |
| 10 | 140 × 0.30 | 7.6土0.5 | 100 |
| 16 | 228 × 0.30 | 9.0±0.5 | 100 |
| 25 | 361 × 0.30 | 10.5±0.5 | 100 |
| 35 | 494 × 0.30 | 12.5土1.0 | 100 |
| 50 | 703 × 0.30 | 13.2±1.0 | 100 |
| 70 | 988 × 0.30 | 15.6士1.0 | 100 |
| 95 | 760 × 0.40 | 17.6土1.0 | 100 |
Note: Products of other specifications can be produced according to the agreement between the supplier and the buyer.
WHY CHOOSE TST
19 quality tests before cable shipment
R&D personnel account for 42% of the company’s headcount
Support all kinds of customization, free sampling
10,000 ㎡ factory, annual production capacity of 2,000,000 meters
