10-24 AWG UL1911 Wire cable 250℃ 6KV-DC high temperature cable PFA PTFE wire

GET A QUOTE

Product features:

Physical properties:

Good mechanical properties
Good high and low temperature resistance
Good flame retardancy
Good corrosion resistance
Good weather resistance
Good lubricity (low friction coefficient)
Excellent radiation resistance
Good bending resistance
Good anti-adhesion performance

Electrical properties:

Good electrical insulation performance
High resistivity

Processing performance:

Use semi-extrusion processing
Good wire harness processing performance
Good compatibility during wire harness processing
Designed according to UL standards

Environmental protection:

Comply with ROHS/REACH
Non-toxic

Application:

Electrical wire, used in places where the temperature does not exceed 250 degrees.

Reference standards:

UL758-2010, UL1581-2009, UL1911

Structural description:

Conductor structure: nickel-plated/silver-plated copper conductor

Insulation material: (PFA) polytetrafluoroethylene alkoxy resin insulation

Single-core conductor unsheathed cable with a conductor temperature of 250°C for electronic gas igniter system UL1911 rated temperature: 250°C

rated voltage: less than or equal to 6KV-DC

model	Specification AWG	Conductor structure (pieces/mm) ±0.005mm	Conductor resistance 20℃ (Q/Km)	Conductor diameter (mm)	（mm)		Finished outer diameter (mm)
model	Specification AWG	Conductor structure (pieces/mm) ±0.005mm	Conductor resistance 20℃ (Q/Km)	Conductor diameter (mm)	Average value	Minimum value	Average value	Tolerance
UL1911 CABLE	10	19/0.61	3.54	3.07	0.71	0.64	4.50
	12	19/0.50	5.64	2.52	0.71	0.64	3.94
	14	19/0.374	8.96	1.88	0.71	0.64	3.30
	16	19/0.3	14.60	1.51	0.71	0.64	2.93
	18	19/0.235	23.20	1.18	0.71	0.64	2.60
	20	19/0.19	36.70	0.95	0.71	0.64	2.37
	22	19/0.15	59.40	0.76	0.71	0.64	2.18
	24	7/0.20	94.20	0.61	0.71	0.64	2.03
Illustrate:In addition to the products of the above specifications, TSTCABLES can also customize other specifications according to your needs. Welcome to email consultation and receive free samples.
