K3 Grade Signal Control Cables
1.Scene Introduction
As an important part of the global energy sector, the nuclear power industry is vital for its safety and stability. In the complex systems of nuclear power plants, K3 grade signal control cables play a key role in transmitting control signals and ensuring the normal operation of equipment. These cables not only need to maintain stable performance in extreme environments, but also need to meet strict safety and environmental standards.
2.The pain point analysis
Traditional cable systems may face multiple challenges in nuclear power plant environments, such as radiation, high temperature, high pressure, and chemical corrosion. These issues may lead to cable performance degradation, unstable signal transmission, and even cause safety hazards. Therefore, it is particularly important to develop a K3 grade signal control cable that can operate stably in a nuclear power environment for a long period of time.
3.The nuclear power K3 signal control equipment on the cable requirements
Nuclear power K3 signal control equipment on the cable requirements are extremely high, mainly including:
Radiation resistance, to ensure that the high radiation environment in the nuclear power plant cable performance is not affected.
High temperature resistance to adapt to the high temperature environment inside the nuclear power plant.
Excellent electrical performance to ensure the stability and accuracy of signal transmission.
High mechanical strength and corrosion resistance to resist the influence of external physical and chemical factors.
4.Certification Standards
Nuclear power K3 signaling control cables must comply with the relevant standards and regulations of the International Atomic Energy Agency (IAEA) as well as the nuclear power safety regulatory bodies of various countries. In addition, the cables are required to pass a series of stringent tests and certifications. For example, the cables should be able to withstand the bunched combustion test specified in the GB/T 18380.3 (IEC332-3) standard, as well as the vertical combustion test specified in the GB/T 18380.1 (IEC332-1) standard. Meanwhile, the low-smoke performance of the cable shall comply with the provisions of GB/T 17651 (IEC61034) standard, and the light transmittance shall be more than 60%; while the low-halogen performance shall comply with the provisions of GB/T 17650.2 (IEC60754-2) standard, and the PH value shall be not less than 4.3, and the conductivity shall be less than 10μs/mm.
Including but not limited to radiation resistance test, high-temperature aging test, electrical performance test.
5.Cable Selection
For the special needs of nuclear power K3 level signal control equipment, TST CABLES chooses to use special PEEK high temperature and heat resistant flame retardant single-core shielded cable, which is seawater resistant, lightweight, small size, flame retardant, low smoke and halogen free flame retardant, high and low temperature resistant, radiation resistant and good mechanical properties. This cable not only has excellent radiation resistance and high temperature resistance, but also can effectively resist external electromagnetic interference to ensure the stability of signal transmission.
Selection parameters for reference (can be customized according to actual needs)
Long-term temperature resistance: -50-250℃
Voltage resistance level: 300V 600V
Gamma ray resistance: 850KGy can be used for a long time.
Low smoke, halogen-free, flame retardant, high and low temperature resistance
6.Product Characteristics
This nuclear power K3 level signaling control cable solution has the following remarkable characteristics:
Excellent electrical performance: with low resistance, high insulation strength and other characteristics to ensure efficient and accurate signal transmission.
Strong environmental adaptability: able to work normally in harsh environments such as high temperature, high humidity, high radiation, etc. and maintain stable electrical performance.
Excellent flame retardant performance: Made of low smoke and halogen-free flame retardant materials, effectively reducing the risk of fire and improving the safety of nuclear power plants.
Moisture resistance: K3 grade signal control cables are carefully designed to resist moisture and humidity, making them suitable for use in environments that require exposure to water or moisture.
Chemical Resistance: These cables exhibit excellent resistance to a wide range of chemicals, including oils, solvents and acids, ensuring their durability and longevity in challenging industrial environments.
Radiation Resistance: K3 rated signal control cables are specifically designed to withstand radiation exposure, making them suitable for use in nuclear power plants and other radiation-prone environments.
High Reliability: These cables are manufactured to stringent quality standards to ensure their long-term reliability and performance in critical applications.
Recommended Products
K3 grade signal control cable is radiation-proof, low-smoke, halogen-free, flame-retardant, and resistant to high and low temperatures. It is an important part of the signal control system and is responsible for transmitting signals and commands between control units and various equipment in industrial environments.
7.Technical Tests
To ensure that the quality and performance of the cables meet the requirements of nuclear power class K3 signaling control equipment, TST CABLES has conducted a series of rigorous technical tests. The tests mainly include the following aspects:
Electrical performance test: verify whether the electrical performance of the cable meets the design requirements by measuring the cable’s resistance, insulation resistance, voltage withstand and other parameters. At the same time, the cable is tested for high-frequency signal transmission to ensure that it can accurately and stably transmit signals.
Environmental adaptability test: simulate the harsh environment of nuclear power plant with high temperature, high humidity, high radiation, etc., and carry out long-time operation test on the cable. Observe the performance changes of the cable in the harsh environment to verify whether it has good environmental adaptability.
Flame-retardant performance test: In accordance with the international standard flame-retardant test methods, the cable is tested for flame-retardant performance. By measuring the burning speed, smoke density and other parameters of the cable, we evaluate whether its flame retardant performance meets the requirements.
Mechanical performance test: The cable is tested for mechanical performance such as tensile, bending and twisting to verify whether it has sufficient mechanical strength and flexibility to meet the installation and operation requirements in the complex environment of nuclear power plants.
After the above tests, this nuclear power K3 signaling control cable solution has excellent performance in all performance indicators and fully meets the relevant standards and requirements of the nuclear power industry.
8.Cable laying installation and commissioning
In the process of laying, installation and commissioning of nuclear power K3 signaling control cable, TST CABLES follows the professional standards and operation procedures of nuclear power projects. First of all, according to the layout of the nuclear power plant and the needs of signal control equipment, develop a reasonable nuclear power cable laying program. Then, professional tools and equipment are used to lay and fix the cables to ensure that the cable routing and fixing points meet the design requirements. Finally, carry out system debugging and testing to ensure the normal operation of signal control equipment and the accuracy of signal transmission.
9.After-sales maintenance & technical support
TST CABLES provides comprehensive after-sales maintenance and technical support services. Once any problem or fault occurs in the nuclear power K3 class signal control cable, our professional team will respond quickly to provide effective solutions and technical support. At the same time, we also carry out regular inspections and maintenance of cables to ensure the long-term stable operation of nuclear power K3 class signal control equipment cables.
10.Actual application examples and relevant data of nuclear power K3 signal control equipment cable program
In the upgrading project of large-scale nuclear power plants along the coast of China, TST CABLES has successfully applied this nuclear power K3 signal control cable solution. In actual operation, the cable shows excellent electrical performance and environmental adaptability, ensuring the stable operation of signaling and control equipment in nuclear power plants. After applying this cable solution, the signal transmission failure rate of this nuclear power plant has been reduced by 90%, which greatly improves the safety, stability and operational efficiency of the plant.
TST CABLES nuclear power K3 signal control cable solution is characterized by excellent electrical performance, environmental adaptability and reliability, which can meet the high requirements of the nuclear power industry on cables. Through TST CABLES’ professional selection, testing, installation and maintenance services, we are able to provide our customers with safe and efficient cable solutions to promote the progress and development of the global nuclear power industry.
