500V 高温耐熱耐摩耗ケーブル 多芯シリコン電線
多芯シリコン高温ケーブルは、長期間の湿気の多い環境で使用でき、優れた電気性能、耐水性、保護機能を備えています。 最小曲げ半径がケーブル径の16倍と優れた曲げ性能を実現。 モバイル使用に適しています。
GET A QUOTE
特徴
- 製品特徴：
- 動作温度: -60~+200℃
- 導体: 錫メッキ銅撚線
- 絶縁： シリコーンゴム
- ジャケット：シリコンゴム
- 色:カスタマイズ可能
選択パラメータ
| 断面積 | 導体構造 | 絶縁 | ジャケット | 20℃では導体抵抗は（Ω/KM）以下 | ||
| mm2 | 厚さ | 外径 | 厚さ | 外径 | ||
| 2*0.2 | 7/0.20 | 0.4 | 1.4 | 0.9 | 4.6 | 94 |
| 3*0.2 | 7/0.20 | 0.4 | 1.4 | 0.9 | 4.8 | 94 |
| 4*0.2 | 7/0.20 | 0.4 | 1.4 | 0.9 | 5.2 | 94 |
| 5*0.2 | 7/0.20 | 0.4 | 1.4 | 1 | 5.8 | 94 |
| 2*0.3 | 16/0.15 | 0.4 | 1.5 | 0.9 | 4.8 | 71.2 |
| 3*0.3 | 16/0.15 | 0.4 | 1.5 | 0.9 | 5 | 71.2 |
| 4*0.3 | 16/0.15 | 0.4 | 1.5 | 1 | 5.6 | 71.2 |
| 5*0.3 | 16/0.15 | 0.4 | 1.5 | 1.2 | 6.4 | 71.2 |
| 2*0.5 | 28/0.15 | 0.5 | 2 | 1 | 6 | 40.1 |
| 3*0.5 | 28/0.15 | 0.5 | 2 | 1.2 | 6.8 | 40.1 |
| 4*0.5 | 28/0.15 | 0.5 | 2 | 1.2 | 7.2 | 40.1 |
| 5*0.5 | 28/0.15 | 0.5 | 2 | 1.2 | 7.8 | 40.1 |
| 6*0.5 | 28/0.15 | 0.5 | 2 | 1.3 | 8.6 | 40.1 |
| 7*0.5 | 28/0.15 | 0.5 | 2 | 1.3 | 8.6 | 40.1 |
| 2*0.75 | 24/0.20 | 0.6 | 2.4 | 1.2 | 7.2 | 26.7 |
| 3*0.75 | 24/0.20 | 0.6 | 2.4 | 1.2 | 7.6 | 26.7 |
| 4*0.75 | 24/0.20 | 0.6 | 2.4 | 1.3 | 8.5 | 26.7 |
| 5*0.75 | 24/0.20 | 0.6 | 2.4 | 1.5 | 9.5 | 26.7 |
| 6*0.75 | 24/0.20 | 0.6 | 2.4 | 1.6 | 10.4 | 26.7 |
| 7*0.75 | 24/0.20 | 0.6 | 2.4 | 1.6 | 10.4 | 26.7 |
| 10*0.75 | 24/0.20 | 0.6 | 2.4 | 1.7 | 12.6 | 26.7 |
| 12*0.75 | 24/0.20 | 0.6 | 2.4 | 1.8 | 13.6 | 26.7 |
| 14*0.75 | 24/0.20 | 0.6 | 2.4 | 1.8 | 14.2 | 26.7 |
| 19*0.75 | 24/0.20 | 0.6 | 2.4 | 1.8 | 15.6 | 26.7 |
| 2*1 | 32/0.20 | 0.6 | 2.6 | 1.2 | 7.6 | 20 |
| 3*1 | 32/0.20 | 0.6 | 2.6 | 1.2 | 7.8 | 20 |
| 4*1 | 32/0.20 | 0.6 | 2.6 | 1.3 | 8.8 | 20 |
| 5*1 | 32/0.20 | 0.6 | 2.6 | 1.5 | 10 | 20 |
| 6*1 | 32/0.20 | 0.6 | 2.6 | 1.6 | 11 | 20 |
| 7*1 | 32/0.20 | 0.6 | 2.6 | 1.8 | 11.6 | 20 |
| 10*1 | 32/0.20 | 0.6 | 2.6 | 1.8 | 13.4 | 20 |
| 12*1 | 32/0.20 | 0.6 | 2.6 | 1.8 | 14.5 | 20 |
| 14*1 | 32/0.20 | 0.6 | 2.6 | 1.8 | 15.2 | 20 |
| 19*1 | 32/0.20 | 0.6 | 2.6 | 1.8 | 16.6 | 20 |
| 2*1.5 | 48/0.20 | 0.6 | 2.8 | 1.3 | 8.5 | 13.7 |
| 3*1.5 | 48/0.20 | 0.6 | 2.8 | 1.3 | 8.5 | 13.7 |
| 4*1.5 | 48/0.20 | 0.6 | 2.8 | 1.4 | 9.5 | 13.7 |
| 5*1.5 | 48/0.20 | 0.6 | 2.8 | 1.5 | 10.6 | 13.7 |
| 6*1.5 | 48/0.20 | 0.6 | 2.8 | 1.8 | 12 | 13.7 |
| 7*1.5 | 48/0.20 | 0.6 | 2.8 | 1.8 | 12 | 13.7 |
| 10*1.5 | 48/0.20 | 0.6 | 2.8 | 1.8 | 14.2 | 13.7 |
| 12*1.5 | 48/0.20 | 0.6 | 2.8 | 1.8 | 15.2 | 13.7 |
| 14*1.5 | 48/0.20 | 0.6 | 2.8 | 1.8 | 16 | 13.7 |
| 19*1.5 | 48/0.20 | 0.6 | 2.8 | 2 | 18 | 13.7 |
| 20*1.5 | 48/0.20 | 0.6 | 2.8 | 2 | 18.5 | 13.7 |
| 24*1.5 | 48/0.20 | 0.6 | 2.8 | 2 | 21.2 | 13.7 |
| 37*1.5 | 48/0.20 | 0.6 | 2.8 | 2.4 | 24.5 | 13.7 |
| 2*2.5 | 49/0.25 | 0.7 | 3.5 | 1.5 | 10 | 8.21 |
| 3*2.5 | 49/0.25 | 0.7 | 3.5 | 1.5 | 10.5 | 8.21 |
| 4*2.5 | 49/0.25 | 0.7 | 3.5 | 1.7 | 12 | 8.21 |
| 5*2.5 | 49/0.25 | 0.7 | 3.5 | 1.8 | 13.2 | 8.21 |
| 6*2.5 | 49/0.25 | 0.7 | 3.5 | 1.8 | 14.2 | 8.21 |
| 7*2.5 | 49/0.25 | 0.7 | 3.5 | 1.8 | 14.2 | 8.21 |
| 10*2.5 | 49/0.25 | 0.7 | 3.5 | 1.8 | 16.8 | 8.21 |
| 12*2.5 | 49/0.25 | 0.7 | 3.5 | 1.8 | 18.2 | 8.21 |
| 14*2.5 | 49/0.25 | 0.7 | 3.5 | 2 | 19.5 | 8.21 |
| 19*2.5 | 49/0.25 | 0.7 | 3.5 | 2.2 | 22 | 8.21 |
| 24*2.5 | 49/0.25 | 0.7 | 3.5 | 2.4 | 26.4 | 8.21 |
| 37*2.5 | 49/0.25 | 0.7 | 3.5 | 2.5 | 29.5 | 8.21 |
